Description
Digital temperature control & monitor system
Keeps food products safe by maintaining constant temperatures
Alarms that sound when doors are not sealed shut; protect against food spoilage that originates from cold air leaks
Early warning alarm program detects issues before malfunction occurs
Digital display allows for easy monitoring
Programs interpret the condition of refrigeration systems by self diagnosis
Rapid cool-down function (Turbo Freeze)
Automatic evaporator fan motor delays
Hydrocarbon refrigerants (R-290)
With innovative and eco-friendly technology, RefrigerationX brings you hydrocarbon refrigerators designed to meet DOEs Energy Conservation Standards in 2017 and to use EPAs SNAP Program approved HC refrigerants. Hydrocarbon refrigerants do not deplete the ozone layer and have very low contribution to global warming (ODP-0, GWP-3).
Cabinet construction
X-line model boasts a stainless steel exterior (door) with AL exterior sides (galvanized steel top, bottom, and back). Interior has a stainless steel bottom with AL interior (walls, door liners, and top duct).
High-density polyurethane insulation
The entire cabinet structure and solid doors are foamed-in-place using high density, CFC free polyurethane insulation.
| ELECTRICAL DATA | |
| Voltage | 115/60/1 |
| Plug Type | NEMA 5-15P |
| Full Load Amperes | 7.9 |
| Compressor HP | 1 |
| Cord Length (ft.) | 9 |
| Refrigerant | R-290 |
| DIMENSIONAL DATA | |
| # of Doors | 3 |
| Net Capacity (cu. ft.) | 65.8 |
| Ext. Length Overall (in.) | 773/4 (1975mm) |
| Ext. Depth Overall (in.) | 307/8 (783mm) |
| Ext. Height Overall (in.) | 78 (1980mm) |
| Int. Length Overall (in.) | 737/8 (1877mm) |
| Int. Depth Overall (in.) | 265/8 (675mm) |
| Int. Height Overall (in.) | 541/8 (1375mm) |
| # of Shelves | 9 |
| Shelf Size (L x D) (in.) | 23 x 231/2 (L/R), 253/8 x 231/2 (M) |
| Net Weight (lbs.) | 540 |
| Gross Weight (lbs.) | 635 |
Warranty
2 Year Parts and Labor
Additional 3-Year Warranty on Compressor
